MODULAR SWITCH CABINET

SWITCH CABINET : VX Type

The VX type industrial electrical cabinet is used to house and protect electrical and electronic components. The purpose of the cabinet is to provide an optimised, secure environment for electrical equipment while facilitating access for maintenance and operations.

The VX electrical cabinet is made of sheet steel to ensure maximum robustness, and its symmetrical width and depth profile maximise the space available. It can be mounted at multiple levels to optimise the interior space and simplify the layout.

View specifications

Technical sheet

Documentation

Fill in the details below to receive the link to download the document.

Checkboxes

ADVANTAGES OF THE HASLER GROUP SWTICH CABINET

SPACE OPTIMISATION

Thanks to the possibility of mounting at several levels, the VX type electrical cabinet allows maximum use of the interior space, offering an effective solution for the arrangement of electrical components. This electrical cabinet can be equipped in a personalised way.

ROBUSTNESS AND INSULATION

Its sheet steel design guarantees maximum robustness, ensuring the protection and durability of electrical components against environmental and mechanical stresses.

SECURITY

This electrical cabinet is specially designed to secure electrical and electronic equipment.

SPACE SAVING

The symmetrical width and depth profile of this electrical cabinet offers an obvious space saving, allowing a modular arrangement on all sides and facilitating its integration in environments where space is limited.

EASE OF ACCESS

Specially designed to facilitate access to electrical equipment, this VX electrical cabinet simplifies maintenance and repair operations and helps reduce industrial system downtime.

APPLICATIONS OF THE HASLER GROUP SWITCH CABINET

The HASLER Group switch cabinet protects all the electronic equipment and electrical installations in a production line, and is useful in various continuous or batch processes.

CEMENT INDUSTRY

Limestone, clay, additives for cement production…

MINING INDUSTRY

Coal, minerals, metals…

CHEMICAL INDUSTRY

Powders, granules, liquid chemicals…

DESCRIPTION OF THE HASLER GROUP SWITCH CABINET



The HASLER Group industrial switch cabinet is designed to secure electrical and electronic equipment.

Specifications of the switch cabinet:

/ Type : VX
/ Dimensions : 2 000x800x500 mm ((other dimensions available on request)
/ Material: steel sheet
/ Base : optional (100 ou 200 mm)
/ Number of doors : 1 (available with 2 doors if the width is greater than 800 mm)
/ Opening system : handle
/ Lock : key
/ Fan and filter : optional on the front
/ Protection : IP54 (or IP 43 if front fan)
/ Lighting : optional
/ Document pouch : yes
/ General switch (red/yellow lockable on door) : Schneider

Internal layout and implementation:

/ Implementation according to EN 60204
/ Wiring : Insulated wires and crimped tips
/ Wire colour : According to EN 60204
/ Wiring marking : Optional (Murrtechnic system)
/ Power : Black
/ Control voltage : AC Red
/ 24 V : DC Blue
/ External voltage : Orange

Internal equipment:

/ Terminals : Wago
/ Transformer : Habermann
/ DC power supply : Wago
/ Circuit breakers : Schneider(C60)
/ Relays : Schneider or Finder
/ Contacts : Schneider
/ Lights, buttons : Schneider
/ Frequency inverter : Schneider / SEW
/ Static inverters (TRIACS) : Phoenix
/ Service socket (max 100 VA European standard) : Schneider

HASLER GROUP GLOBAL SUPPORT SERVICE



To optimise the performance and availability of your electronic equipment, our experts can provide a wide range of services, including:

/ Mechanical audits, industrial process audits and laboratory tests.

/ On-site services for the assembly, commissioning and maintenance of your equipment, together with preventive or corrective repairs, with or without remote assistance.

/ Carrying out material tests and dosing precision tests.

/ Upgrade/revamping/retrofit operations aiming to:

  • Improve the reliability of your dosing equipment, manage the obsolescence of SCM automation and set up remote support.
  • Optimise your processes by adapting them to new flow or material constraints and addressing production defects (clogging, fusing and precision problems).
  • Maximise the performance of your mechanical equipment, including abrasion resistance (for parts such as belts).

/ Training modules to strengthen your teams’ skills on your dosing solutions.

/ Advice to support your teams and the availability of spare parts, including:

Controllers
Electronic cards (I/O, communication, etc.)
Weight sensors (digital and analogue)
Display and programming consoles
Speed measuring devices (encoders, measuring wheels).
Mechanical components (rollers, drums, extrusion screws, etc.)
Rubber belts
