Powder belt feeder POWDRIT 2 : precise measurement of powdery materials
Powder belt feeder POWDRIT 2 : precise measurement of powdery materials
The POWDRIT 2 belt feeder is a complete solution for industrial processes requiring precise metering of powdered materials. The modular design and sealed settling chamber of this powder feeder ensure the stability of the powdered materials, guaranteeing consistent performance. The POWDRIT 2 dosing solution is the latest generation of the POWDRIT belt feeder designed by our experts. It combines performance, accessibility, modularity, and safety to meet the demands of continuous industrial processes (24/7). This belt feeder for powders is designed to optimize user experience and maintenance operations.
Its accuracy of ±0.25 % makes it an indispensable solution for weigh feeding in various industrial applications. This feeder solution offers smooth, safe operation thanks to its high-quality conveyor belt and comprehensive dust extraction system.
Technical sheet
Advantages of the POWDRIT 2 powder weigh feeder
Precision and reliability
This equipment feeds to a precision of ± 0.25% and ensures accurate measurements in all conditions.
Performance and intelligence
Its analogic sensor and ultra-precise electronic control enhance the performance of the POWDRIT 2 feeder. Its high-quality belt centring and tensioning system (available as an option) ensures automatic belt alignment and optimum tension.
Accessibility
Load cells, bearings (lubrication), belt index, belt deviations and rollers, handling of standard weights... thus optimized user experience and faster maintenance.
Modularity
The POWDRIT 2 industrial dosing system consists of a basic module with a settling chamber and options, all equipped with plug & play functionality with all our controllers.
Safety
The basic module and options comply with the requirements of the Machinery Directive 2006/42/EC, even without protective covers.
Durability
This equipment has been designed by our mechanical experts to guarantee robust, long-life construction suited to demanding, severe operating conditions.
Simplified servicing and maintenance
With the BCD (Belt Changeover Device) option: an ergonomic tool designed to facilitate easy replacement without the need to support the equipment. It allows for installing a new belt three times faster.
Applications of the POWDRIT 2 powder feeder
BUILDING MATERIALS INDUSTRY
Cement…
CHEMICAL INDUSTRY
Powders, pigments…
METALLURGICAL INDUSTRY
Coal…
Description and operation of POWDRIT 2 the powder weigh feeder
Specifically designed to meet the demands of continuous industries (24/7), the POWDRIT 2 belt feeder stands out for its robustness, particularly due to its folded beams which provide good structural stability.
The POWDRIT 2 powder feeder guarantees precise dosing of powdered materials through a multi-stage process:
1. Extraction
2. Stabilization of the material in the settling chamber
3. Dosing
The POWDRIT powder feeder guarantees precise feeding of powdered materials thanks to a multi-stage process.
It consists of an inlet hopper, a conveyor belt, a weighbridge and a settling chamber.
The POWDRIT 2 is fed by a pre-dosing system, with level measurement by an analogic sensor.
The material is transported on a high-quality belt, and the feeder is electronically controlled to maintain constant precision.
It consists of an inlet hopper combined with a settling chamber, a conveyor belt, and a weighing bridge.
Finally, it has a dust extraction hood for a clean, safe working environment.
POWDRIT 2 powder feeder is controlled by the SCMIII controller, which collects the data and signals essential for calculating flow, total quantities and regulation functions. All the information and alarms triggered during the feeding operation are also transmitted to the PDU console and displayed in real time. A single console can be used to interface with multiple feeders (up to 8).
POWDRIT 2 is the ideal continuous dosing solution for following processing : raw flour, lime, fly ash, powdered limestone, gypsum, lime, wood sawdust, animal meal, phosphate flour, filter dust (filler), apatite, concentrated phosphorite, phosphate mill, rock flour.
POWDRIT 2 industrial belt feeder for powders is available with numerous options.
Options:
/ Material cover with hinged access hatch
/ Belt Changeover Device (BCD), tool to ease belt replacement
/ Emergency control
/ Self-centering with or without automatic belt tensioning
/ Belt slip control
/ Rope emergency switch
/ Abrasion-resistant conveyor belt
/ High-temperatures conveyor belt
/ Complete stainless-steel construction
/ Other qualities & paint colors
/ ATEX version
/ Spillage conveyor
HASLER Group global support services
To improve the performance of your equipment and the availability of your industrial installations, our experts can help you with:
/ Technical audits or industrial process audits and tests : feeding precision test.
/ Supplies of material tests, simulations and filtration tests.
/ Revamping, retrofit and upgrade services to make your feeder systems more reliable, with or without remote assistance.
/ Revamping/retrofit services to improve your industrial feeder processes: Changes to processes (flow rate, materials), production defects (clogging, fusing, feeder precision), extended operating range (speed 1–100%).
/ Retrofit and mechanical revamping services for your feeder equipment: abrasion resistance (belt), calibration chain.
/ Des services de rétrofit, revamping mécanique pour vos équipements de dosage : résistance à l’abrasion (tapis, bande), chaine d’étalonnage et de calibration.
/ Revamping /retrofit/upgrade services for your ATEX compatibility.
/ Training on your equipment to upgrade the skills of your maintenance or production teams.
/ Advice and supplies of spare parts: controller, electronic boards (I/O, communication, etc.), display and programming consoles, weight sensors (digital and analogue), mechanical parts (rollers, drums, extrusion screws, etc.), rubber belts, metal weighing elements, speed measurement (encoders, measuring wheels), etc.
